Orifice Flanges

Name: Orifice Flanges
Brand: Texas Flange
Availability: InStock

Orifice flanges are crucial in industrial processes. You use Orifice Flanges with orifice meters to measure liquid and gas flow accurately. They contain a precise orifice plate for reliable measurement while ensuring system integrity.

Texas Flange produces top-notch orifice flange that meet industry standards. For over 30 years our products are known for accuracy, strength, and reliability, offering exceptional performance for various applications in monitoring flow and control.

REQUEST A QUOTE

Types of Orifice Flange Offered by Texas Flange

While orifice flange share similarities with standard pipe flange, they come in different configurations to suit various piping requirements. Texas Flange offers:

For larger sizes exceeding 24 inches, Texas Flange supplies orifice flange manufactured to the MSS SP-44 standard, ensuring superior performance even in the most demanding environments.

We Are Ready To Help With Your Flange Needs

Key Features of Orifice Flanges

Pressure Taps

Our orifice flange come with machined pressure tap holes, simplifying installation and delivering accurate pressure readings without additional pipe tappings.

Jack Screws

Orifice flange include jack screws for easy removal during installation, inspection, and maintenance tasks. It helps quickly remove flange to replace orifice plates and gaskets.

Precision Orifice Plate

The key element of the system that causes a pressure drop proportional to the flow rate is the orifice plate, which has a carefully measured opening. Texas Flange ensures that every orifice plate is tailored for precision and dependability according to unique service conditions.

High-Performance Gaskets

Orifice flange available with a spiral wound or RTJ gaskets with raised face or RTJ face for secure seals.

Industries That Use Orifice Flange

Orifice flange are used in multiple industries that need to measure flow accurately.

Oil and gas

In the oil and gas industry, the flow of crude oil, natural gas, and petroleum products is measured.

Chemical processing

Chemicals are controlled to ensure accurate measurement and quality control.

Power generation

In power generation plants, gauge the flow of steam, water, and fluids to enhance efficiency.

Water treatment

In water treatment plants for measuring water flow and wastewater for correct treatment.

Food and beverage

In food and beverage processing, oversee the flow of components for consistent quality.

Pharmaceutical

In pharmaceutical manufacturing, the flow of pharmaceutical substances is monitored for precision and safety.

High-Quality Materials for Every Application

At Texas Flange, we understand that each application has unique requirements. That’s why we offer orifice flange in a variety of materials, including:

Carbon Steel (ASTM A105) — A cost-effective solution for general applications.
Low-Temperature Carbon Steel (ASTM A350 LF2) — Designed for low-temperature environments.
Stainless Steel (ASTM A182 F316/F304) — Providing excellent corrosion resistance for aggressive fluid environments.
Alloy Steels (ASTM A182 F11, F22) — Engineered for enhanced strength and resistance in specific corrosive conditions.

The wide variety of materials available allows Texas Flange to meet the needs of any operating environment, including high-pressure pipelines and corrosive fluid systems.

Sizes and Standards: Meeting Every Need

Various sizes and pressure ratings of orifice flange, ranging from 300 to 2500, are offered to cater to multiple pipe diameters and industrial applications. All products comply with ASME B16.36 and MSS SP-44 requirements to ensure superior quality and reliability. Texas Flange offers top-quality solutions for accurate flow measurement if your project is in oil and gas, chemical processing, or another high-stakes industry.

Why Choose Texas Flange for Your Orifice Flange?

Accurate Flow Measurement

We design our orifice flange for precision, optimizing pressure tap locations and configurations to ensure precise pressure differential readings.

Easy Installation and Maintenance

The integrated pressure taps and jack screws make installation and maintenance faster and more straightforward, reducing downtime.

Cost-Effectiveness

Texas Flange provides cost-effective orifice flange with standard sizes to reduce costs for installation and maintenance in the long run.

Versatility Across Industries

We create our products to work effectively across various settings and sectors, from high-pressure steam applications to corrosive chemical environments.

Frequently Asked Questions

Orifice flange play a significant role in industries like oil and gas, chemical processing, power generation, and water treatment, where accurate flow measurement is essential.

Orifice flange contain pressure taps that are carefully machined to calculate the pressure variation across the orifice plate, which is essential for accurate flow measurement. Furthermore, they come with jack screws to make installation and maintenance easier.

Texas Flange offers orifice flange made from various materials, including carbon steel, stainless steel, low-temperature carbon steel, and alloy steel, to suit multiple operating conditions.

Our orifice flange come in pressure classes of 300 to 2500, suitable for various industrial uses and pipe dimensions.

Texas Flange is a trustworthy provider known for high-quality materials, precise design, and outstanding customer support. We engineer our orifice flange to comply with industry standards and deliver reliable performance in every application.
